-86℃ Dual Cooling Ultra Low Temp. Medical Refrigerator — Cialan

Cialan is the first tier manufacturer and supplier of ultra low temperature freezer in China, we provide ultra low lab freezer, pharmacy refrigerators, deep freezer fridge and professional after-service.

-40℃~-86℃

Temperature Range

408L/588L/728L/838L

Capacity

LCD

Display

Product Details Characteristics Parameter Message

Quote Now Send Email

Product Details

Dual-cooled refrigerators are designed with two independent cooling systems to provide extra protection for biomedical samples. The dual cooling system maximizes reliability, longevity and efficiency. Under normal operating conditions, the two independent systems are activated sequentially at intervals.

Characteristics

The Dual Cooling System is designed with two independent cooling systems to provide additional protection for biological samples. The dual cooling system maximizes reliability.

In the event of an unexpected failure of one of the systems, the other system will maintain the temperature in the -70℃ range, ensuring that sensitive samples are not threatened alone.

Under normal operating conditions, the 2 independent systems are activated sequentially at intervals. The two systems then work together for rapid cooling performance.

The refrigerator features a 7-inch LCD touchscreen with Android operating system, enabling users to operate it easily and quickly.

The multi-layer sealing design saves energy and keeps heat out, while better insulation helps keep the freezer cooler for longer and reduces noise during operation.

Tags:

-86C ULT freezer

Parameter

Model	CNF-86V408D	CNF-86V588D	CNF-86V728D	CNF-86V838D
Technical data
Temperature Range	-40℃~-86℃
Defrost	Manual
Cooling Type	Direct Cooling System
Temp. Controller	Microprocessor
Ambient Temperature	10℃~32℃
Temp Fluctuation	±1℃
Display	LCD
Shelf/Drawer	Stainless Steel Shelf/3	Stainless Steel Shelf/3	Stainless Steel Shelf/3		Stainless Steel Shelf/3
Insulation	PURF	VIP plus PURF	VIP plus PURF		VIP plus PURF
Racks	16(5X4,4X4)	16(5X5)	12(5X4)+12(6X4)		24(5X5)
Capacity（L/cu.ft)	408/14.40	588/20.76	12608902010		119010452010
Boxes (2 Inches)	288	400	504		600
Samples Loading QTY(2ml)	28800	40000	50400		60000
Dimensions(WDH)(mm)	9009401940	88511001995	12608902010		119010452010

Components of Dual Cooling Medical Refrigerator

Application of low temperature freezer and refrigerator

Cases of low temperature freezer and refrigerator
