Graphite Furnace Atomic Absorption Spectrophotometer For Trace Analysis — Cialan

Cialan is the first tier manufacturer and supplier of aa spectroscopy in China, we provide graphite atomic absorption spectroscopy, flame aa spectroscopy, cold vapor atomic absorption spectroscopy and professional after-service.

190 – 900nm

Wavelength Range

0.1nm,0.2nm,0.4nm,1.0nm,2.0nm

Bandwidth

Graphite atomizer

Product Details Characteristics Parameter Message

Quote Now Send Email

Product Details

GF AAS spectrometer Complete automatic controlling system:With the help of the software, the following can be easily achieved:
1.Selection of the element lamp
2.Up-down-front-rear adjustment of the lifter
3.Adjustment of the optical energy
4.Selection of the slit
5.Determination of wavelength scanning and peak searching
6.Selection of the atomizer
7.Setting of the background deduction method
8.Controlling of the gas flow
9.Automatic flaming and flaming out
10.Setting of the graphite furnace testing method

Characteristics

Completely controlled by PC, can flexibly select the flame and graphite furnace atomizer (optional).

Integrated floated optical platform design can obviously improve the optical system shock resistance and can keep stable though use the optical signal for a long term.

Eight light stands can be changed automatically and preheat the eight element lights meantime as well as optimize the working condition of the hollow cathode lamp.

Position adjusting: the best height of the flame burner and can automatically set the front and rear positions.

Fully automated wavelength scanning and peak searching.Deuterium lamp and self-absorption background regulation.

Complete safety chains protection equipment: the function of warning and automatic safety protection towards the wrong burner, leakage of the gas, under voltage of air and the abnormal flame out.

Data processing: super strong database, possesses more than 500 data self-storage and cut-off storage function.

Measuring method: flame absorption method and emission method.Result printing: parameter printing, data result printing and diagram printing.

Tags:

Graphite furnace atomic absorption spectrophotometer

Parameter

Model:AA-4530F
Optical System
Wavelength range	190-900nm
Spectral bandwidth	Can automatically change between 0.1nm, 0.2nm, 0.4nm, 1.0nm and 2.0nm
Accuracy of the wavelength	±0.15nm
Receptivity of the wavelengt	≤0.04nm
Base line stability	≤0.002A/30min (Cu)
Characteristic viscosity	0.02μg/ml/1% (Cu)
Checking limit	0.004μg/ml (Cu)
Preciseness	0.5%
Grating	1800 lines/mm
In flamer	All-metal titanium burner
Atomizer	Effective glass atomizer
Lamp stand	Eight lamps
Flame Method
Acetylene air burner	100mm
Nitrous oxide acetylene flame head	50mm
Ignition dynamic baseline drift	≤0.006A/30min
(Cu) Characteristic viscosity	≤0.025μg/ml/1%
Related standard deviation of the accuracy	≤0.5%(Cu, absorbance＞0.8A) (detection limit Cu≤0.008μg/ml)
Graphite furnace
The highest temperature	3000℃
The largest temperature rising speed	≥2000℃/S
Characteristic quantity	Cd≤0.5×10-12g Cu≤0.5×10-11g
Accuracy	Cu≤3% Cd≤3%
Safety system	Over current protection
